DD-T10
LED moving head par can light
Voltage:AC100-240V/50-60Hz
Light source:Cree CXA1512 LEDs<
Lamp power:18W
CCT:normally 3200k or custom made for customers.
LED moving head par can light product description:
Voltage:  AC100-240V/50-60Hz
Power:  32W
LEDs:  Cree CXA1512 LEDs
LEDs power:  18W
LEDs life:  50000-100000 hours
Color Temp:  normally 3200k or custom made for customers.
CRI:  ≥93, TLCI≥91
Luminous flux:  940 Im
Beam angle:  10° or custom made for customer
Motor:  step motor
Motor’s voltage:  12V/0.5A
Motor’s speed:  5/min. (adjustable depend on customer’s requires)
Pan:  360°
Tilt:  ±30°
Control signal:  DMX
DMX channel:  4 channels or add channels depend on customer’s require
Control model:  DMX or manual button
Dimming:  16BIT above smooth flicker-free dimming, dimming not delay,  frequency 20k above.
Ambient temperature:  -25℃-40℃
IP rating:  IP20
Housing color:  white or black
Inner size:  Φ20.5×22cm
Hole’ s diameter  for hang on ceiling:  Φ18.2cm
Packing size:  24X24X26.3cm
Net weight:  3.6kg
Gross weight:  4kg
